Specifications: Brand Name: ANENG Model Number: Q1 Operating Temperature: 0 – 40 ° Operating Humidity: ≤75%RH Storage Condition: -20~60° Storage Humidity: ≤80%RH DIY Supplies: Electrical Operating Mode: Auto/Manual Ranging Measuring Inductance Range: no Measuring Temperature Range: -20~1000 C/-4F-1832F Measuring Capacitance Range: 9.99nF/99.99nF/999.9nF/9.99uF/99.99uF/999.9uF/9.999MF Measuring Voltage Range: 999.9mV/9.999V/99.99V/999.9V Measuring Current Range:999.9uA/99.99uA/999.9mA/10A Measuring Resistance Range: 99.99/999.9/9.999k/99.99k/999.9K/9.999M/99.99M Ohm Frequency: 99.99Hz/999.9Hz/9.999KHz/99.99KHz/999.9KHz/5MHz Display Type: Digital Display Diode Test: Yes Continuity: Yes Duty Cycle: 1%-99% Sample Rate: 3 times per second Power: 2 * 1.5V AA batteries(Not Included) Notes: 1. Do NOT exceed the “maximum value” indicated in the Specification; 2. Do NOT input voltage at the Current Mode, the Resistance Mode, the Diode Mode, the Continuity Mode, or the Temperature Mode; 3. Do NOT use the product when the batteries or the battery cover is not placed properly; 4. Turn off the product and remove the test leads from the test points before changing batteries or fuses. 5. Do not input voltage exceeds 36V DC or 25V AC when you are at the setting of measuring current. Packaging content: 1 x Multimeter 1 x Test lead temperature sensor 1 x User Manual 1 x Storage bag 1 x 16pc Test probe ANENG Q1 True-RMS Digital Multimeter Button 9999 Counts With Analog Bar Graph AC/DC Voltage Ammeter Current Ohm Auto/Manual Please Note you have to reading the operate manual first before use,otherwise you will burn the device with wrong operat.
