AC Input Rated Input Voltage (VAC): 208 / 220 / 230 / 240; L N PE Frequency (Hz): 50 / 60 (Auto Adaptive) AC Output Rated Capacity (kW): 4 Surge Power (kVA): 8 Voltage (VAC): 208 / 220 / 230 / 240 Power Factor (PF): 1 Frequency: 50/60Hz±0.1% Switch Time (ms): 10 (normal mode) / 10 (UPS mode) Wave Form: Pure Sine Wave Overload Capacity (Battery Mode): 60s@102%~110% load 10s@110%~130% load 3s@130%~150% load 0.2s@>150% load Max. Efficiency (Battery Mode): 92.7%@24VDC Parallel Quantity: NA Charger (PV / AC) Solar Charger Type: MPPT Max PV Input Current / Input Power: 18A / 5000W MPPT Range @ Operating Voltage (VDC): 40~450 Max PV Open Circuit Voltage (VDC): 500 Max PV Charge Current (A): 100 Max AC Charge Current (A): 100 Max. Charge Current (PV AC) (A): 100 Battery Rated Voltage (VDC): 24 Floating Charge Voltage (VDC): 27 Overcharge Protection (VDC): 30.5 Battery Type: Lithium and Lead-acid Interface HMI: LCD Interface: RS485 / RS232 / USB / Dry Contact Monitoring: WiFi (Optional) General Data Ingress Protection: IP21 Operating Temperature: -10°C ~ 50°C Relative Humidity: 5% ~ 95% (Non-condensing) Storage Temperature: -15°C ~ 60°C Net Weight (kg): 6.4 Dimensions (WHD): 490306115mm (without bracket) Max. Operating Altitude: 4000m (Derating above 1000m)
