FESTO – 539150 – Electromechanical Electrovalves – ICDC-040051 – New Main Category: Electromechanical | Sub-Category: Electrovalves | Status: New Original ComponentsFESTO Part Number: 539150 | ICDC Internal Part Number: ICDC-040051 539150 Description: Valve function 2×3/2-way, monostable, closed Type of actuation Electric Construction width 26 mm Standard nominal flow rate 900 l/min pneumatic working port Sub-base size 26 mm to ISO 15407-1 Sub-base size 01 to VDMA 24563 G1/4 Operating voltage 24V DC Operating pressure 0.3 MPa … 1 MPa Operating pressure 3 bar … 10 bar Design Piston gate valve Approval c UL us – Recognized (OL) Degree of protection IP65 NEMA 4 Exhaust-air function With flow control option Via throttle plate Via individual sub-base Sealing principle Soft Mounting position optional Manual override Detenting Non-detenting Covered Type of piloting Pilot actuated Pilot air supply External Internal Flow direction Non-reversible Symbol 00991817 lap Positive overlap Signal status display LED Pilot pressure 0.3 MPa … 1 MPa Pilot pressure 3 bar … 10 bar Flow rate of valve 1250 l/min Flow rate of valve on individual sub-base 1100 l/min Valve flow rate, pneumatically linked, flow optimized 1150 l/min Flow rate of pneumatically interlinked valve 900 l/min Switching time off 38 ms Switching time on 20 ms Duty cycle 100% Max. positive test pulse with 0 signal 1500 µs Max. negative test pulse with 1 signal 1200 µs Max. current consumption 60 mA Nominal operating voltage DC 24 V Characteristic coil data 24 V DC: 1.3 W Immunity to surge 2.5 kV Pollution degree 3 Permissible voltage fluctuations /- 10 % Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required) Vibration resistance Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6 Shock resistance Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27 Corrosion resistance class CRC 0 – No corrosion stress Relative air humidity 0 – 90% Pilot medium Compressed air to ISO 8573-1:2010 [7:4:4] Ambient temperature -5 °C … 50 °C Product weight 335 g Electrical connection Plug-in To ISO 15407-2 Type of mounting On sub-base Pilot air port 12/14 Sub-base size 26 mm to ISO 15407-2 Pilot exhaust port 82/84 Ducted Not ducted as per standard Either: Pneumatic connection, port 1 Sub-base size 26 mm to ISO 15407-2 Pneumatic connection, port 2 Sub-base size 26 mm to ISO 15407-2 Pneumatic connection, port 3 Sub-base size 26 mm to ISO 15407-2 Pneumatic connection, port 4 Sub-base size 26 mm to ISO 15407-2 Pneumatic connection, port 5 Sub-base size 26 mm to ISO 15407-2 Note on materials RoHS-compliant Material seals FPM HNBR NBR Material housing Die-cast aluminium PA Material screws Galvanised steel Contact us to discover 539150. ICDCSPARES.COM offers new or overhauled original components, ready in stock to be shipped via DHL Express! Call us! Check our Electromechanical section to discover more about ICDC catalog: a large selection of industrial spare parts including Fuses, Electric Motors, Switches and Electrovalves.Are you looking for industrial Solenoid Valves? ICDC offers online a wide selection of Electrovalves of the most important OEMs like EATON, ABB and DANFOSS, besides FESTO. ICDC, Your Industrial One Stop Shop for Components!
