Description: 2.4G WiFi RF Touch Remote wireless Smart Phone MiLight RGB led Controller Dimmer Mi.Light 4-zone WiFi / 2.4G RF Remote RGB Control System for RGB LED Strip Lights About ” Mi.Light 4-zone WiFi / 2.4G RF Remote RGB Control System ” The basic components of the system are: 1. Touch Remote 2. RGB LED controller 3. WiFi Controller Android/IOS Mobile App : Milight The basic Features of the system as below: 1. RGB led strip Light connected to the RGB led controller 2. Remote control the Light 3. Wifi control the light. 4. Remote and WiFi Control the light at the same time. [Remote and WiFi are same functions] The Special Features of the system as below: 1. One remote can control countless controllers in 4 Zones Individually or Simultaneously 2. One WiFi can control countless controllers in 4 Zones Individually or Simultaneously 3. Remote and WiFi can control countless controllers at the same time. [Remote and WiFi are same functions] 4. One led controller can be controlled by 4 remotes / WiFi [ such as: 3 remote and 1 WiFi etc…] Frequently asked questions: 1. Can I control Zone1 or Zone2 or Zone3 or Zone4 Individually with no change the color in other Zones? Re: Yes, you can, Just press key “Zone on” (the remote include 4 “Zone On” keys for Zone1 to Zone4) to choose which Zone you are going to control. then choose the color or brightness or Mode according to the color ring or brightness ring or Mode key on remote. 2. Sometime I want to control Zone1 to Zone4 individually, sometime i want to control Zone1 to Zone4 together so Zone1 to Zone4 display same color. is it easy? or I must change the connection and link all controllers to one Zone? Re: It is very easy and no need to change the connection. please Long press “Master On”, you will see white on. then choose the color or brightness or Mode according to the color ring or brightness ring or Mode key on remote. you will see all led strip in Zone1 to Zone4 changing together and display same color/same changing. once you want to back to control Zone1 to Zone4 individually. just press key “Zone On” to choose the Zone. then you can control this Zone individually. 3. Can I use this item to control the RGB Led strip to display and dimming and hold White? Re: Yes , you can, please note: For RGB LED strip light, the white is mixed from Red, Green and Blue, so the white is not pure, we call it Mixed-White 4. What is the control distance and frequency? Re: The remote control system is designed to IEEE 802.15.4 standards, the remote distance is 30meter, and the frequency is 2.4GHz, And for the smart phone, you can control your lights everywhere all over the world. 5. I have Mi.Light 4-Zone 1x remote 1x Controller already , can I order Remote or wifi or controller from you and add these new items to my original control system? Re: Yes, if your original items are Mi.Light series , you can order new item from us and add these new item to your system. Description: With the technology of the 2.4G high frequency wireless remote control, it has the characteristics of low power consumption, long distance transmission, and strong anti-interference ability ,high speed telecommunications, etc.The remote looks fashionable and elegant , with simple and practical functions of color changing and brightness dimming, the capacitive touch screen design makes the remote easy to use. The WiFi controller/Bridge can be used to all Mi Light the 2.4G smart light series, RGB light bulb, RGB light bulb/down light, dual white light bulb/down light, etc. With this simple WiFi controller, you can control your lights with iOS 5.0 or Android smart phone App, free download from Apple App Store, or Android Google Play with the new App name: Mi ·light, automatically setting and you are ready to go! Program List: Program 1 (RGBW Fade In Fade out) This program fades in and fades out the color red, green, blue and white one after another. Program 2 (Color Flash) In this program, red, green, blue, white purple flashes to change. Program 3 (Disco) Different colors strobe and flash to change. Program 4 (Red color Ramp up and Flash) In this program, red color brightnes from 0% – 100% and shuts down, then flashes three times. Program 5 (Green color Ramp up and Flash) In this program, green color brightens from 0% – 100% and shuts down, then flashes three times. Program 6 (Blue color Ramp up and Flash) In this program, blue color brightens from 0% – 100% and shuts down, then flashes three times. Program 7 (Color Change Flash) Here several colors fade into each other and then flash randomly. Program 8 (Fade in and Fade out) Here different colors fade into each other. Program 9 (Strobe White) Just white color flashes up. Tips: To dim all RGB lights at once or change the color, first press ‘Master ON’ to do this with individual lights, first press ‘ZONE ON’ to active which ZONE you are going to control. Secondly, choose the color or brightness according to the color ring or brightness ring. For RGB LED strip light, the white is mixed from Red, Green and Blue, so the white is not pure Linking new lights to the remote controls: 1. Choose which zone you want to assign the light (1 to 4) 2. Switch off the main power supply of the light in the selected zone with the main switch or pull the plug from the socket. 3. Now switch on the light again and within 3s shortly press one of the ‘Zone On’ buttons one time on the remote control. 4. When this link operation is successful, the light slowly blinks 3 times on and off or on in random color. Unlinking the lights: 1. Check via the remote control to see whick zone (1 to 4) is already linked to a light. 2. Switch off the main power supply of the light with the main switch or pull the plug from the socket. 3. Now switch on the light again and within 3s long press 3s-5s on one of the ‘Zone On’ button which you want to unlink. 4. When this unlink operation is successful. the light quickly blinks 6 times on and off. Grouping of several lights You can add an endless numbers of lights to a zone on the 4 channel remote by linking the lights to different zones. This way you are completely flexible in creating different group combinations. Mi.Light RGB Controller Technical Data: Size: 85 x 45 x 23mm Working Voltage: DC12-24V, Input Method: DC 5.5 x 2.1 Female connector input and 2 wire( -) input Control Way: R G B Three Channels (Red Green Blue) Max Load per Channel: 6A Output Connection: Common anode Telecontrol Distance:30meters Programs:9 Types Mi.Light 4-Zone Color Temperature FUT035 LED Strip Controller Technical Data: Size: 85 x 45 x 22.5mm Working Voltage: DC12V-24V Output Max: 6A/Channel, Total output Max. 10A Control Distance: 30 meters Mi.Light LED Single Color Dimmer FUT036 Technical Data: Size: 85 x 45 x 22.5mm Working Voltage: DC12V-24V Output Max: 6A/Channel, Total output Max. 10A Control Distance: 30 meters Mi.Light RGBW Controller FUT038 Technical Data: Size: 85 x 45 x 23mm Working Voltage: DC12-24V RGBW LED Strip Input Method: DC 5.5 x 2.1 Female connector input and 2 wire( -) input Control Way: R G B W Four Channels Max Load per Channel: 6A Output Connection: Common anode Telecontrol Distance:30meters Programs:9 Types Mi.Light RGB CCT Strip Controller FUT039 Technical Data: Product Name: 2.4GHz RGB CCT LED Strip Controller Model No.: FUT039(Upgraded) Working Voltage: DC12V~24V Working Temperature: -20~60°C Output Max: 6A/Channel Total Output Max:12A RF: 2.4GHz Transmitting power: 6dBm Control Distance: 30m Output connection: Common anode Mi Light WiFi Controller – WiFi Bridge Technical Data: Size: 90 x 66 x 15mm Working Voltage:DC5V, 500mA Input Method: USB Material: ABS Telecontrol Distance: 30meters Output Radio Frequency: 2.4G RF to Mi.Light controller Input Radio Frequency:Wifi From IOS/Android system. Mi-Light – APP Free Download iOS app for iOS 5 or later (iPhone / iPad)– Search Milight Android App for Android 2.2 or higher — Search Milight RGBWW Remote Model No.: FUT092 Voltage: 3V (2 x AAA batteries) Transmission Frequency: 2.4GHz Modulation Method: GFSK Transmitting Power: 6dBm Standy Power Consumption: 20uA Control Distance: 30m Size: 138*56*38mm Please select from the below: Remote FUT096 1 x 2.4G RF touch Pad Remote (2xAAA batteries are not included) 1 x English manual 1 x Box Controller FUT035 1 x 2.4G Mi-Light 12-24v RGB led controller 1 x English manual 1 x Box Controller FUT036 1 x 2.4G Mi-Light 12-24v RGB led controller 1 x English manual 1 x Box Controller FUT037 1 x 2.4G Mi-Light 12-24v RGB led controller 1 x English manual 1 x Box Controller FUT038 1 x 2.4G Mi-Light 12-24v RGBW led controller 1 x English manual 1 x Box Controller FUT0398 1 x 2.4G Mi-Light 12-24v RGBW led controller 1 x English manual 1 x Box WiFi Controller Module 1 x Wifi 2.4G Mi-Light Controller / bridge 1 x USB connection cable 1 x English manual 1 x Box RGBWW Remote 1 x 2.4G RF touch Pad Remote (2xAAA batteries are not included) 1 x English manual 1 x Box
