Description Key Features Battery-Optional Operation: A game-changer for budget-conscious users, this series can power loads directly from the PV array without a connected battery, reducing initial system costs. High Voltage MPPT: Supports a Maximum PV Open Circuit Voltage up to 500V (Model dependent), allowing for longer solar string configurations and reducing wiring costs. Dual AC Output: Featured on most models (2012/3624/4024/6048/6248), this function provides a secondary output for non-critical loads, offering smarter energy distribution (Note: 5248 PRO model has single output). Pure Sine Wave & High Efficiency: Delivers clean, stable power for sensitive electronics with a peak inverter efficiency of 93%. Smart Communication: Built-in WIFI/RS485/CAN interfaces support remote monitoring and direct communication with Lithium Battery BMS for enhanced safety and performance. Parallel Capability: (Check specific model support) Allows for system expansion to meet growing energy needs. Applications Flexible Off-Grid Living: Perfect for homes or cabins where battery investment might be delayed; start with just solar panels and the inverter. Hybrid Systems: Ideal for areas with unstable grids, seamlessly blending Solar, Utility, and Battery power. Heavy Load Management: Dual output models help manage heavy vs. essential loads automatically. Core Specifications Table Model PV18-2012 PRO PV18-3624 PRO PV18-4024 PRO PV18-5248 PRO PV18-6048 PRO PV18-6248 PRO Rated Power 2000W 3600W 4000W 5200W 6000W 6200W Battery Voltage 12VDC 24VDC 24VDC 48VDC 48VDC 48VDC Surge Power 3200W 6000W 7000W 10400W 11000W 12400W Max PV Voltage (VOC) 400VDC 400VDC 450VDC 450VDC 450VDC 500VDC MPPT Voltage Range 30~320VDC 30~320VDC 60~360VDC 150~430VDC 60~360VDC 120~450VDC Max Solar Charge 80A 100A 100A 100A 100A 120A Max AC Charge 80A 60A 60A 80A 100A 100A Dual Output Yes Yes Yes Yes Yes Yes Dimensions (mm) 318*370*121 318*454*122 318*454*122 309*505*147 318*454*122 318*454*122 Net Weight 6.2 kg 7.4 kg 7.6 kg 12.9 kg 9.4 kg 10.0 kg
