■ Pure sine wave output ■ Smart LCD setting (Working modes, Charge Current, Charge Voltage, etc). ■ Built-in MPPT solar charge controller ■ Combining solar system, AC utility, and battery power source to supply continuous power ■ Overload, short circuit and Deep discharge protection ■ Cold start function ■ Support USB, RS485, CAN monitoring function ■ WIFI remote monitoring (Built in wifi module and antenna) ■ PV/ AC activation function ■ BMS communication function (CAN Port) ■ Dual output for smart load management MODEL PV18-1612 PREM PV18-2524 PREM PV18-3024 PREM PV18-3524 PREM PV18-5548 PREM Nominal Battery System Voltage 12VDC 24VDC 24VDC 24VDC 48VDC INVERTER OUTPUT Rated Power (Main Second Load) 2000VA/1600W 2500VA/2500W 3000VA/3000W 3500VA/3500W 5500VA/5500W Surge Power 3200W 5000W 6000W 7000W 11000W Waveform Pure sine wave AC Voltage Regulation (Batt.Mode) 230VAC±5%(Setting) Inverter Efficiency(Peak) 90~93% Transfer Time 10ms (UPS / VDE4105) / 20ms (APL) AC INPUT Voltage 230VAC±5% Selectable Voltage Range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VED4105) Frequency Range 50Hz / 60Hz(Auto sensing) BATTERY Normal voltage 12VDC 24VDC 24VDC 24VDC 48VDC Floating Charge Voltage 13.7VDC 27.4VDC 27.4VDC 27.4VDC 54.8VDC Overcharge Protection 15VDC 30VDC 30VDC 30VDC 60VDC SOLAR CHARGER &AC CHARGER Maximum PV Array Open Circuit Voltage 400VDC 400VDC 400VDC 450VDC 450VDC Maximum PV Input Current 16A 18A 18A 18A 28A Charging Algorithm 3-Step (Flooded Battery, AGM / GEL / LEAD Battery), 4-Step (Li) Maximum PV Array Power 2000W 4000W 4000W 4000W 6000W PV Array MPPT Voltage Range(Typ.) 30~320VDC 60~360VDC Maximum Solar Charge Current 80A 100A Maximum AC Charge Current 80A 60A 60A 60A 100A Maximum Charge Current 80A 100A MECHANICAL SPECIFICATIONS Machine Dimension (W*H*D)(mm) 290*367*111 290*367*111 290*367*111 318*367*122.5 318*454*122.5 Package Dimension (W*H*D)(mm) 446*394*187 446*394*187 446*394*187 459*410*200 544.5*410*200 N.W (kg) 6.4 6.6 6.6 7.2 9.0 G.W (kg) 7.4 7.6 7.6 8.2 10.5 OTHER Humidity 5% to 95% Relative humidity (Non-condensing) Operating Temperature 0°C~50°C Storage Temperature -15°C~60°C Warranty 2years CERTIFICATION & STANDARDS CE-EMC LVD (EN6100-6-3, EN6100-6-1 EN IEC62109-1, EN IEC62109-2)
