■ Pure sine wave output ■ Smart LCD setting (Working modes, Charge Current, Charge Voltage, etc). ■ Built-in MPPT solar charge controller ■ Wide PV input voltage range ■ Can provide the power to the load without battery ■ Combining solar system, AC utility, and battery power source to supply continuous power ■ Overload, short circuit and Deep discharge protection ■ Cold start function ■ Support RS485,CAN monitoring function ■ Dual outputs for smart load management ■ Can communicate with lithium batteries (CAN port) MODEL PV18-1612 ECO PV18-2524 ECO PV18-3024 ECO PV18-3524 ECO PV18-5548 ECO PV18-6248 ECO Default Battery System Voltage 12VDC 24VDC 24VDC 24VDC 48VDC 48VDC INVERTER OUTPUT Rated Power 2000VA/1600W 2500VA/2500W 3000VA/3000W 3500VA/3500W 5500VA/5500W 6200VA/6200W Output Channel Dual Dual Dual Dual Dual Dual Surge Power 3200W 5000W 6000W 7000W 11000W 12400W Waveform Pure sine wave AC Voltage Regulation (Batt.Mode) 230VAC±5%(Setting) Inverter Efficiency(Peak) >90% Transfer Time Typical < 10ms , 20ms max AC INPUT Voltage 230VAC Selectable Voltage Range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VDE) Frequency Range 50Hz / 60Hz (Auto sensing) BATTERY Normal voltage 12V 24VDC 24VDC 24VDC 48VDC 48VDC Floating Charge Voltage 13.7VDC 27.4VDC 27.4VDC 27.4VDC 54.8VDC 54.8VDC Overcharge Protection 15VDC 30VDC 30VDC 30VDC 60VDC 60VDC SOLAR CHARGER & AC CHARGER Maximum PV Input Voltage 400VDC 400VDC 400VDC 450VDC 450VDC 500VDC Charging Algorithm 3-Step (Flooded Battery, AGM / GEL / LEAD Battery), 4-Step (Li) Maximum PV Array Power 2000W 4000W 4000W 4000W 6000W 6200W PV Array MPPT Voltage Range(Typ.) 30~320VDC 30~320VDC 30~320VDC 60~360VDC 60~360VDC 120~450VDC PV maximum input current 16A 18A 18A 18A 28A 28A Maximum Solar Charge Current 80A 100A 100A 100A 100A 120A Maximum AC Charge Current 80A 60A 60A 60A 100A 100A Maximum Charge Current 80A 100A 100A 100A 100A 120A MECHANICAL SPECIFICATIONS Machine Dimension (W*H*D)(mm) 290*367*111 290*367*111 290*367*111 318*367*122.5 318*454*122.5 318*428*140 Package Dimension (W*H*D)(mm) 446*394*187 446*394*187 446*394*187 446*410*200 544.5*410*210 550*400*220 N.W (kg) 6.4 6.7 6.7 7.3 9.0 10.0 G.W (kg) 7.4 7.7 7.7 8.3 10.5 11.6 OTHER Humidity 5% to 95% Relativ Humidity (Non-condensing) Operating Temperature 0°C~50°C Storage Temperature -15°C -60°C Warranty 2years CERTIFICATION & STANDARDS CE
