Description Key Features Unmatched Safety Standards: Safety is paramount. Every LP2800 unit comes standard with a Built-in Explosion-Proof function. For extreme environments, optional Fire Suppression and internal Heating functions (for freezing climates) are available, providing total peace of mind. Massive Single-Unit Capacity: Choose from 100Ah, 200Ah, 300Ah, and the new ultra-dense 314Ah (16.07kWh) models. A single high-capacity unit can power an average home through the night, saving installation space and wiring time. High Power Output (Up to 10KW): The 300Ah and 314Ah models support a massive 200A Maximum Continuous Discharge, delivering 10KW of output power to effortlessly run heavy loads like HVAC systems, well pumps, and EV chargers. IP65 Indoor & Outdoor Ready: The fully sealed metal cabinet is rated IP65, protecting the battery from dust and water jets. It can be safely installed in basements, garages, or outdoors (away from direct sunlight). Smart WiFi BMS: Features a built-in WiFi and BLE module. Users can monitor real-time data, cell health, and State of Charge (SOC) from anywhere using the dedicated smartphone app. Exceptional 10-Year Warranty: Powered by top-tier Lithium Iron Phosphate cells, it delivers an incredible ≥8000 cycles at 25°C. MUST backs this with a comprehensive 10-Year Warranty. Massive Scalability: The intelligent BMS allows up to 15 units to be connected in parallel, enabling a staggering maximum system capacity of 241.14kWh for commercial or luxury estate applications. Universal Inverter Compatibility: Pre-programmed to communicate flawlessly (via CAN/RS485) with over 25 mainstream inverter brands globally. Applications High-End Residential Solar: The sleek design and high power output make it perfect for modern, energy-independent homes. Harsh Environments: The IP65 rating and optional heating function make it ideal for off-grid cabins in cold or humid climates. Safety-Critical Installs: The explosion-proof and fire suppression features are perfect for indoor utility rooms where safety codes are strict. Core Specifications Table (All models operate at 51.2V Nominal Voltage.) Model LP28-48100 LP28-48200 LP28-48300 LP28-48314 Nominal Voltage 51.2V 51.2V 51.2V 51.2V Nominal Capacity 100Ah 200Ah 300Ah 314Ah Nominal Energy 5.12 kWh (5120Wh) 10.24 kWh (10240Wh) 15.36 kWh (15360Wh) 16.07 kWh (16076Wh) Max Output Power 5 KW 7.5 KW 10 KW 10 KW Max Cont. Charge/Discharge 100A 150A 200A 200A Cycle Life ≥8000 Cycles ≥8000 Cycles ≥8000 Cycles ≥8000 Cycles Dimensions (W*H*D) mm 500 * 620 * 175 500 * 892.5 * 150 500 * 980 * 250 500 * 980 * 250 Net Weight ≈ 52 kg ≈ 92 kg ≈ 118 kg ≈ 119 kg Installation Mode Floor / Wall-Mount Floor-Mount Only Floor-Mount Only Floor-Mount Only Protection Rating IP65 IP65 IP65 IP65 Communication CAN/RS485/WIFI/BLE CAN/RS485/WIFI/BLE CAN/RS485/WIFI/BLE CAN/RS485/WIFI/BLE
