Description ■ CPU controlled ■ Auto re-starts when AC recovers ■ Silence setup ■ Automatic charging(offline charging) ■ Battery low voltage protection ■ Overload short circuit protection ■ Wide input voltage range ■ AVR function ■ Cold start function ■ Generator compatible MODEL EW2110-600 EW2110-1200 EW2110-2000 RatedPower 650VA/390W 1200VA/720W 2000VA/1200W INPUT Input Voltage 110V/120 VAC or 220/230/240 VAC Input Voltage range 85-145VAC/145-290VAC 85-145VAC/175-275VAC Input Frequency 45~65 Hz OUTPUT AC Output Port 2 3 2 Output Voltage 110/120 VAC or 220/230/240 VAC Output Voltage range 102-132VAC/200-255VAC 102-132VAC/200-240VAC Output frequency 60±0.5 Hz or 50±0.5 Hz (Auto sensing) Output Wave form PWM (Batt. mode) Transfer time Typical 2-6ms,10ms max BATTERY QTY. & capacity of battery 12V/7ah*1pcs 12V/7ah*2pcs 12V/9ah*2pcs Charge time 4-6 hours recover to 90% capacity PROTECTION Full protection Low voltage & overload & short circuit protection PHYSICAL Machine Dimension(W*H*D)(mm) 284*95*140 345*146*162 345*122*192 N.W(kg) 3.9 7 11 G.W(kg) / / / Standard Warranty 1years ENVIRONMENT Environment of performance Temperature 0°C~ 40°C, Humidity 20%~90% Noise level Less than 40dB MANAGEMENT LCD or LED, RJ45/11 & USB (optional) Remark: EW series indicate LED UPS, EW-C series indicate LCD UPS.
