Description ■ With double conversion online design, zero output transfer time. ■ Adopt DSP digital control ■ Adopt the technology of active power factor correction technology (PFC) ■ With LCD LED real-time display ■ With 3-5 minutes can work when on full loads. ■ Cold start by battery without grid Input. ■ Input frequency range 40~70Hz MODEL EH55-H1K2 EH55-H1K3 EH55-H3K6 EH55-H3K8 Rated Capacity 1KVA/1KW 3KVA/3KW INPUT Input format L N PE Rated input voltage 208/220/230/240VAC Voltage range 110~300VAC Frequency range 50/60±6Hz (Default), ±10Hz (Settable) Input power factor ≥0.99 Input total harmonic distortion ≤4% linear load OUTPUT AC Output Port 3 Output format L N PE Output voltage 208/220/230/240VAC Output accuracy ±1% Output frequency For on-line mode: follow current frequency, battery mode: 50/60Hz±0.1% Output harmonic distortion ≤ 2% linear load; ≤ 4% nonlinear load (PF=0.7) PF 1 Overload capacity AC mode 30min@102%~110% Load; 10min@110%~130% Load; 30s@130%~150% Load; 200ms@>150% Load Batterymode 10min@102%~110% Load; 1min@110%~130% Load; 10s@130%~150% Load; 200ms@>150% Load SWITCHING TIME Switch to battery mode 0ms Switch to bypass 4ms AC priority mode Support EFFICIENCY AC Mode (Full Load) 94.5%@220VAC 95.5%@220VAC Battery Mode for without built-in battery (Full Load) 88.5%@36VDC 91.5%@96VDC Battery Mode for withbuilt-in battery (Full Load) 87.5%@24VDC 91.5%@72VDC BATTERY Battery type Lead Acid Battery Rated Battery Voltage 24V 36V 72V 96V Battery Spec 2*12V/9Ah 3*12V/7Ah 6*12V/9Ah 8*12V/7Ah Number of InternalBattery 2/3(optional) 6/8(optional) Chaging current Built-in battery 1K-3K: 1A (Default) 1-2A (Adjustable) Without built-in battery 1KS-3KS: 5A (Default) 1-12A (Adjustable) Charging mode Two-stage/three-stage charging DISPLAY LCD 2×8PIN/Pitch2.54mm, support 128-bit segment code, up to 4 buttons 4 LEDs, can display operating mode / load / input / output, etc. INTERFACE RS-232 Support: Windwos 2000/2003/XP/Vista/2008/7/Linux/Unix and MAC USB Windows Famlly & MAC Intelligent slot(Optional) SNMP/AS400 Relay Card/RS485 EPO (Optional) Support ENVIRONMENTAL PARAMETERS Operating ambient temperature 0~40°C Operating environment humidity 20%~95% (no condensation) Storage temperature -15~60°C (batteries: 0~40°C ) Altitude The elevation should not exceed 1000m, 1000m or above, up to 4000 m, reference IEC62040 Noise ≤45db MECHANICAL SPECIFICATIONS Machine Dimension(W*H*D)(mm) 143*222*285 143*222*354 192*326*397 Package Dimension(W*H*D)(mm) 235*320*380 235*320*448 312*452*527 N.W (kg) 7.5 10 20 24 G.W (kg) 8.5 11 21.5 25.5 Standard Warranty 1years
