Description: T-300k System features 32—256 grade Gray level,Support software Gamma correction. Support the rules and special-shaped handle. 8 ports output,one port can support 512-1024 lamp pixels. On-line (also can SD Card) control, offline control Can be multiple controllers used in combination, the contents of the line control program stored in the SD card. Compatible with single line or double line chips. If the controller to the lamps distance can choose photoelectric isolated transmission and as far as several distances of up to 200-300 M. Note: the T-300 K controller offline control, each machine controller must put a SD card. 2012 Edition T-300K controller can only be combined with the new version software LedEdit2012. Using the old software does not support the new version of the controller, the new version of the controller has been printed the Chinese sign. Supported chips: Supported chips: Software code& Controller type Lamps/(MAX) NOTE LPD6803,D705,1101,6909, 6912 T-300K-6803 8192 32 grade gray level LPD8806,LPD8809 T-300K-8806 4096/8192 TM1803,TM1804,TM1809,TM1812 T-300K-TM 4096/8192 TM1804&TM1809 Divided into high speed and low speed TM1903,TM1904,TM1909,TM1912 T-300K-TM19 4096/8192 UCS6909,UCS6912,UCS7009,UCS5903 T-300K-UCS32 8192 UCS1903,UCS1909,UCS1912 T-300K-UCS256 4096/8192 Divided into high speed and low speed UCS3903 T-300K-UCS1024 4096/8192 DMX512 T-300K-DMX 1360/4096 Compatible with standard DMX512 WS2801,WS2803 T-300K-WS 4096/8192 WS2811 T-300K-WS2811 4096/8192 Divided into high speed and low speed DS189 T-300K-DS189 4096/8192 TLS3001,TLS3002,TLS3008 T-300K-TLS 4096/8192 P9813 T-300K-P9813 4096/8192 SM16715 T-300K-SM16715 4096/8192 Divided into high speed and low speed SM16716 T-300K-SM16716 4096/8192 BS0901,BS0902 T-300K-0901 4096/8192 BS0815 T-300K-0815 4096/8192 NOTE: if chip is 256 grade gray level and Single-line IC choose .When programming choice high speed mode and one interface controls 1024 lamps the play speed can reach 30 frames/s. Double-line IC or single-line IC with low speed , one interface controls 512 lamps the play speed can reach 30 frames/s. The meaning of flag TTL signal(245 signal): AC IN Exchange 220V power supply COM(common port) GND (ground wire) POWER POWER LIGHT DAT Signal STATUS Status light CLK The clock line SD CARD SD card slot NOTE: According to TTL signal output, Ground of the controller must be connected to the lamp ground. What you will receive: 1 x LED Controller 1 x SD Card
